WSSB – Welded Stainless Steel IP68 Environmentally Protected S-Type Load Cell
The WSSB S-Beam load cell series is ideal for measuring both tension and compressive forces. The standard metric threads at each end of the load cell are designed to accept standard spherical seating rod-end bearings. The WSSB is suitable for many applications where a tension and compression load cell is required for high accuracy measurements. Applications such as vessel weighing, material test machines, and dynamometers are a few examples. The WSSB series can be supplied on its own or combined with our extensive range of instrumentation to provide a complete load monitoring system.
- Capacities from 551 lbf to 44.1K lbf (250kg to 20MT)
- Stainless steel fully welded construction
- Environmentally sealed to IP68
- Can be supplied complete with mating spherical rod-end bearings
U.S. dimensions and capacities are provided for conversion only. Standard products have International System of Units (SI) capacities and dimensions
