ZEISS INSPECT Correlate Software

ZEISS INSPECT Correlate Software


Digital image correlation and point tracking algorithms for 3D testing data

Turn videos into meaningful measurement data. With ZEISS INSPECT Correlate, you can analyze dynamic processes such as displacements, rotations or angle changes. Intuitive to use and equipped with practical functions, the software optimally supports you in your 3D testing applications. Use digital image correlation and point tracking algorithms for sub-pixel accurate measurement of 3D coordinates and track them over time.

ZEISS INSPECT Correlate: Easy evaluation of dynamic measurements

  • Intuitive to use
  • Fast analyses
  • Individual functions with apps

Fast analyses with ZEISS INSPECT Correlate

ZEISS INSPECT Correlate boasts numerous functions – some of which can be customized – to capture, analyze and process measuring data. ZEISS INSPECT Correlate will simplify your data evaluations – thus saving time and costs.

Faster and more efficient evaluations

Our is based on a parametric concept. Thanks to version control, you can keep track of all process steps, edit them and re-run them, thus accelerating the evaluation of the measuring data and ensuring ease-of-use of the software.

  • Project templates for faster evaluations and automated reporting.
  • Definition of different coordinate systems for evaluations, including the application for rigid body motion compensations.
  • Extensive filter options for all measuring data.

Optimal features for your process

ZEISS INSPECT Correlate has a wide range of helpful features that will optimize both your process and workflow, such as:

  • Extensive evaluation functionalities: 6DoF analyses, trajectories, virtual extensometers, combining scan data with motion measurement
  • CAD and FEM import including alignments
  • Measurement of geometries with probes and not directly visible measuring points via adapter
  • Sensor connectivity: generic USB3 cameras, high-speed cameras, ARAMIS sensors and photogrammetry solutions
  • Python interface: record operations performed in the software, save, edit and reuse for (partially) automated evaluations


Customize to meet your needs

ZEISS INSPECT Correlate gives you the option to add all the functionalities you might need. Just choose from the following packages:

  • Determination of material characteristics based on tensile, Nakajima and bulge tests
  • Import of FEM data sets and full-field comparison between measuring data & simulation data
  • Thermo-mechanical deformation analysis using temperature data from thermographic cameras


ZEISS INSPECT Correlate in action

Pictures say more than a thousand word. See for yourself how other customers are using ZEISS INSPECT Correlate and the amazing versatility that the software offers.


Start now with the ZEISS Quality Suite

Find the perfect introduction to ZEISS INSPECT: Whether a trial version, a live demonstration, or the direct purchase of the software – it’s up to you. Whether you decide to try out or purchase directly, simply download the ZEISS Quality Suite in which you then install ZEISS INSPECT

ZEISS INSPECT Correlate has extensive digital image correlation capabilities and captures and measures 3D coordinates with sub-pixel accuracy. You can create and customize your own project templates. You’ll also achieve efficient throughput thanks to improved software workflows, more compatibility options and packages with software add-ons. Within the ZEISS Quality Suite you can easily access all our services, trainings, updates, feature packages and more. Convince yourself now and experience the numerous advantages with our free trial version, which you can easily activate in your ZEISS Quality Suite. After the 14-days trial period, you can continue to use the basic version of the software free of charge without any obligations.
